可實現高靈敏度和低噪聲圖像採集的三片1/2英寸的Exmor CMOS™成像器。
全高清XAVC內部和XAVC長GOP，以及MPEG HD 422 50 Mbps的，MPEG HD 420 Mbps的35，MPEG IMX和DV。
包括用於同步錄製雙的SxS存儲卡槽，緩存錄製功能，“慢動作和快動作”功能和3.5英寸QHD(960×540)彩色液晶螢幕。
帶物理止點的獨立聚焦，變焦和光圈控制環，能夠從29.3毫米到499毫米變焦（35mm格式等效轉換下）。
通過智能手機和平板設備實現遠程控制、文件傳輸、視頻預覽以及串流媒體功能*。 *串流媒體功能需要固件升級。
| Camera | |
|---|---|
| Imaging Device | 3 x 1/2" type Exmor CMOS sensor |
| Effective Pixels | 1920x1080 (2.07 million pixels), per sensor |
| Sensitivity | F12 (typical, 1080/59.94i mode) F13 (typical, 1080/50i mode) |
| S/N Ratio | 58 dB, typical |
| Shutter Speed | 1/32 to 1/2,000 sec |
| White Balance | Preset (3200K), Memory A, Memory B/ATW |
| Lens | |
|---|---|
| Type | Fixed |
| Zoom Ratio | 17x (optical), servo/manual |
| Focal Length | 5.6 to 95.2 mm |
| 35mm Equivalent Focal Length | 29.3 to 499 mm |
| Aperture | f/1.9 to f/16 and close, auto/manual selectable |
| Focus Distance | 31.5" (800 mm) to infinity (Macro Off) 2.0" (50 mm) to infinity (Macro On, Wide) 31.5" (800 mm) to infinity (Macro On, Tele) AF/MF/Full MF selectable |
| Image Stabilizer | On/Off selectable, shift lens |
| Filter Diameter | 77 mm, pitch 0.75 mm |
| Recording | |
|---|---|
| Video Recording Format | exFAT XAVC-Intra mode: CBG, max. 112 Mbps, MPEG-4 H.264/AVC 1920x1080p 23.98/25/29.97 1920x1080i 50/59.94 1280x720p 50/59.94 XAVC-Long 50 mode: FBR, max. 50 Mbps, MPEG-4 H.264/AVC 1920x1080p 23.98/25/29.97/50/59.94 1920x1080i 50/59.94 1280x720p 50/59.94 XAVC-Long 35 mode: VBR, max. 35 Mbps, MPEG-4 H.264/AVC 1920x1080p 23.98/25/29.97/50/59.94 1920x1080i 50/59.94 XAVC-Long 25 mode: VBR, max. 35 Mbps, MPEG-4 H.264/AVC 1920x1080i 50/59.94 MPEG HD422 mode: CBR, 50 Mbps, MPEG-2 422P@HL 1920x1080p 29.98/25/29.97 1920x1080i 50/59.94 1280x720p 23.98/25/29.97/50/59.94 MPEG HD420 HQ mode: VBR, max. 35 Mbps, MPEG-2 MP@HL 1920x1080p 23.98/25/29.97 1920x1080i 50/59.94 1440x1080p 23.98/25/29.97 1440x1080i 50/59.94 1280x720p 23.98(2-3 Pull Down)/50/59.94 DVCAM mode: CBR, 25 Mbps, DVCAM 720x480i 59.94 720x480PsF 29.97 720x576i 50 720x576PsF 25 UDF MPEG HD422 mode: CBR, 50 Mbps, MPEG-2 422P@HL 1920x1080p 29.98/25/29.97 1920x1080i 50/59.94 1280x720p 23.98/25/29.97/50/59.94 MPEG HD420 HQ mode: VBR, max. 35 Mbps, MPEG-2 MP@HL 1920x1080p 23.98/25/29.97 1920x1080i 50/59.94 1440x1080p 23.98/25/29.97 1440x1080i 50/59.94 1280x720p 23.98(2-3 Pull Down)/50/59.94 MPEG IMX50 mode: CBR, 50 Mbps, MPEG-2 422P@ML Intra 720x486i 59.94 720x486PsF 29.97 720x576i 50 720x576PsF 25 DVCAM mode: CBR, 25 Mbps, DVCAM 720x480i 59.94 720x480PsF 29.97 720x576i 50 720x576PsF 25 FAT MPEG HD420 HQ mode: VBR, max. 35 Mbps, MPEG-2 MP@HL 1920x1080p 23.98/25/29.97 1920x1080i 50/59.94 1440x1080p 23.98/25/29.97 1440x1080i 50/59.94 1280x720p 23.98(2-3 Pull Down)/50/59.94 MPEG HD420 SP mode: CBR, 25 Mbps, MPEG-2 MP@H-14 1440x1080p 23.98(2-3 Pull Down) 1440x1080i 50/59.94 DVCAM mode: CBR, 25 Mbps, DVCAM 720x480i 59.94 720x480PsF 29.97 720x576i 50 720x576PsF 25 |
| Audio Recording Format | exFAT XAVC-Intra mode: LPCM 24-bit, 48 kHz, 4 channel XAVC-Long mode: LPCM 24-bit, 48 kHz, 4 channel MPEG HD422 mode: LPCM 24-bit, 48 kHz, 4 channel MPEG HD420 HQ mode: LPCM 16-bit, 48 kHz, 4 channel DVCAM mode: LPCM 16-bit, 48 kHz, 4 channel UDF MPEG HD422 mode: LPCM 24-bit, 48 kHz, 4 channel MPEG HD420 HQ mode: LPCM 16-bit, 48 kHz, 4 channel IMX50 mode: LPCM 24/16-bit, 48 kHz, 4 channel DVCAM mode: LPCM 16-bit, 48 kHz, 4 channel FAT MPEG HD420 HQ mode: LPCM 16-bit, 48 kHz, 4 channel MPEG HD420 SP mode: LPCM 16-bit, 48 kHz, 4 channel DVCAM mode: LPCM 16-bit, 48 kHz, 2 channel Proxy: AAC-LC, 48 kHz, 128 kbps, 2 channel |
| Slow & Quick Motion Function | XAVC Intra/Long mode: 1080p: 1-30 and 60 fps in NTSC setting; 1-25 and 50 fps in PAL setting 720p: 1-60 fps in NTSC setting; 1-50 fps in PAL setting MPEG HD422 mode: 1080p: 1-30 fps in NTSC setting; 1-25 fps in PAL setting 720p: 1-60 fps on NTSC settings; 1-50 fps in PAL setting MPEG HD420 HQ mode: 1080p: 1-30 fps 720p: 1-60 fps |
| Interface | |
|---|---|
| Video Output | 1 x SD/HD/3G-SDI, BNC connector 1 x HDMI, Type A |
| Composite Output / GENLOCK-IN | 1 x BNC |
| Audio Input | 2 x XLR 3-pin (female) |
| Audio Output | 1 x A/V multi-connector |
| TC Input / Output | 1 x BNC |
| Lens Remote Control Connector | 1 x 8-pin, round |
| DC Input | 1 x DC jack |
| USB | 1 x USB mini-B connector |
| Shoe Mounts | 1 x Multi-Interface |
| Headphone Output | 1 x 3.5 mm stereo mini jack |
| IEEE-1394 (FireWire/DV/iLink) | 1 x 4-pin, Type A |
| Monitoring | |
|---|---|
| LCD | 3.5" (8.89 cm) type 960 x 540 x 3 (RGB) 16:9 |
| Viewfinder | 0.45" (1.14 cm) type 960 x 540 x 3 (RGB) 16:9 |
| Recording Media | |
|---|---|
| Slots | 2 x ExpressCard/34; supports SxS cards (for XAVC/MPEG/IMX/DV) 1 x SD/SDHC (for Proxy) |
| General | |
|---|---|
| Built-In Microphone | Omni-direction stereo electret condenser microphone |
| Wi-Fi | Yes (with included IFU-WLM3 wireless module) |
| NFC | Yes |
| Power Requirements | 12 VDC |
| Power Consumption | Approx. 18 W (while recording with LCD Off, EVF On, I/O Select Off, and wireless function Off) Approx. 23 W (while recording with LCD On, EVF Off, HD-SDI output, and wireless function On) |
| Battery Operating Time | BP-U90: approx. 4.5 hours BP-U60: approx. 3 hours BP-U30: approx. 1.5 hours (while recording with LCD Off, EVF On, I/O Select Off, and wireless function Off) |
| Operating Temperature | 32 to 104° F (0 to 40° C) |
| Storage Temperature | -4 to 140° F (-20 to 60° C) |
| Dimensions (WxHxD) | 6.61 x 6.34 x 13.03" (16.8 x 16.1 x 33.1 cm) (without protrusions) |
| Weight | Approx. 5.29 lb (2.4 kg) (body only) Approx. 6.17 lb (2.8 kg) (with lens hood, eyecup, BP-U30 battery, and SxS memory card) |
